sysvorOrt /boot/grub # grub-install /dev/sdb
x86_64-efi wird für Ihre Plattform installiert.
grub-install: Fehler: EFI-Verzeichnis kann nicht gefunden werden.

Cannot find EFI directory: issue with grub-install


Wenn Sie grub-install standardmäßig ausführen, wird davon ausgegangen, dass das EFI-System als /boot/efi gemountet ist.Es hängt von Ihrer Distribution ab, wo das EFI-System gemountet ist, und bei einigen Distributionen wird es nach dem Booten nicht gemountet.

Überprüfen Sie zunächst, ob /boot/efi mit gemountet ist

mount | grep /boot/efi

Wenn das nicht funktioniert, versuchen Sie zunächst Folgendes, um festzustellen, ob es woanders gemountet ist.

mount | grep /dev/[efi-Gerät]

Wenn keine dieser Arbeiten funktioniert:

Mounten Sie /dev/[EFI-Gerät] /mnt

Führen Sie nun Folgendes aus:

grub-install –efi-directory=[efi dir]
grub-mkconfig -o /boot/grub/grub.cfg

Dabei ist [efi dir] entweder /boot/efi oder /mnt und [efi device] das Gerät mit der EFI-Systempartition. Wenn Sie es nicht wissen, verwenden Sie den Befehl lsblk -o NAME,PARTTYPE,MOUNTPOINT | grep -i „C12A7328-F81F-11D2-BA4B-00A0C93EC93B“

Die Konfigurationsdatei von Grub (/boot/grub/grub.cfg) :



# DO NOT EDIT THIS FILE
#
# It is automatically generated by grub-mkconfig using templates
# from /etc/grub.d and settings from /etc/default/grub
#

### BEGIN /etc/grub.d/00_header ###
if [ -s $prefix/grubenv ]; then
  load_env
fi
if [ "${next_entry}" ] ; then
   set default="${next_entry}"
   set next_entry=
   save_env next_entry
   set boot_once=true
else
   set default="0"
fi

if [ x"${feature_menuentry_id}" = xy ]; then
  menuentry_id_option="--id"
else
  menuentry_id_option=""
fi

export menuentry_id_option

if [ "${prev_saved_entry}" ]; then
  set saved_entry="${prev_saved_entry}"
  save_env saved_entry
  set prev_saved_entry=
  save_env prev_saved_entry
  set boot_once=true
fi

function savedefault {
  if [ -z "${boot_once}" ]; then
    saved_entry="${chosen}"
    save_env saved_entry
  fi
}

function load_video {
  if [ x$feature_all_video_module = xy ]; then
    insmod all_video
  else
    insmod efi_gop
    insmod efi_uga
    insmod ieee1275_fb
    insmod vbe
    insmod vga
    insmod video_bochs
    insmod video_cirrus
  fi
}

if [ x$feature_default_font_path = xy ] ; then
   font=unicode
else
insmod part_gpt
insmod ext2
set root='hd1,gpt2'
if [ x$feature_platform_search_hint = xy ]; then
  search --no-floppy --fs-uuid --set=root --hint-bios=hd1,gpt2 --hint-efi=hd1,gpt2 --hint-baremetal=ahci1,gpt2  f24c114f-f71c-4834-8aa3-357788352a2f
else
  search --no-floppy --fs-uuid --set=root f24c114f-f71c-4834-8aa3-357788352a2f
fi
    font="/usr/share/grub/unicode.pf2"
fi

if loadfont $font ; then
  set gfxmode=auto
  load_video
  insmod gfxterm
  set locale_dir=$prefix/locale
  set lang=en_US
  insmod gettext
fi
terminal_output gfxterm
if [ x$feature_timeout_style = xy ] ; then
  set timeout_style=menu
  set timeout=5
# Fallback normal timeout code in case the timeout_style feature is
# unavailable.
else
  set timeout=5
fi
### END /etc/grub.d/00_header ###

### BEGIN /etc/grub.d/10_linux ###
menuentry 'Gentoo GNU/Linux' --class gentoo --class gnu-linux --class gnu --class os $menuentry_id_option 'gnulinux-simple-f24c114f-f71c-4834-8aa3-357788352a2f' {
	load_video
	if [ "x$grub_platform" = xefi ]; then
		set gfxpayload=keep
	fi
	insmod gzio
	insmod part_gpt
	insmod ext2
	set root='hd1,gpt2'
	if [ x$feature_platform_search_hint = xy ]; then
	  search --no-floppy --fs-uuid --set=root --hint-bios=hd1,gpt2 --hint-efi=hd1,gpt2 --hint-baremetal=ahci1,gpt2  f24c114f-f71c-4834-8aa3-357788352a2f
	else
	  search --no-floppy --fs-uuid --set=root f24c114f-f71c-4834-8aa3-357788352a2f
	fi
	echo	'Loading Linux 6.1.9-gentoo-x86_64 ...'
	linux	/boot/vmlinuz-6.1.9-gentoo-x86_64 root=UUID=f24c114f-f71c-4834-8aa3-357788352a2f ro
	echo	'Loading initial ramdisk ...'
	initrd	/boot/initramfs-6.1.9-gentoo-x86_64.img
}
submenu 'Advanced options for Gentoo GNU/Linux' $menuentry_id_option 'gnulinux-advanced-f24c114f-f71c-4834-8aa3-357788352a2f' {
	menuentry 'Gentoo GNU/Linux, with Linux 6.1.9-gentoo-x86_64' --class gentoo --class gnu-linux --class gnu --class os $menuentry_id_option 'gnulinux-6.1.9-gentoo-x86_64-advanced-f24c114f-f71c-4834-8aa3-357788352a2f' {
		load_video
		if [ "x$grub_platform" = xefi ]; then
			set gfxpayload=keep
		fi
		insmod gzio
		insmod part_gpt
		insmod ext2
		set root='hd1,gpt2'
		if [ x$feature_platform_search_hint = xy ]; then
		  search --no-floppy --fs-uuid --set=root --hint-bios=hd1,gpt2 --hint-efi=hd1,gpt2 --hint-baremetal=ahci1,gpt2  f24c114f-f71c-4834-8aa3-357788352a2f
		else
		  search --no-floppy --fs-uuid --set=root f24c114f-f71c-4834-8aa3-357788352a2f
		fi
		echo	'Loading Linux 6.1.9-gentoo-x86_64 ...'
		linux	/boot/vmlinuz-6.1.9-gentoo-x86_64 root=UUID=f24c114f-f71c-4834-8aa3-357788352a2f ro
		echo	'Loading initial ramdisk ...'
		initrd	/boot/initramfs-6.1.9-gentoo-x86_64.img
	}
	menuentry 'Gentoo GNU/Linux, with Linux 6.1.9-gentoo-x86_64 (recovery mode)' --class gentoo --class gnu-linux --class gnu --class os $menuentry_id_option 'gnulinux-6.1.9-gentoo-x86_64-recovery-f24c114f-f71c-4834-8aa3-357788352a2f' {
		load_video
		if [ "x$grub_platform" = xefi ]; then
			set gfxpayload=keep
		fi
		insmod gzio
		insmod part_gpt
		insmod ext2
		set root='hd1,gpt2'
		if [ x$feature_platform_search_hint = xy ]; then
		  search --no-floppy --fs-uuid --set=root --hint-bios=hd1,gpt2 --hint-efi=hd1,gpt2 --hint-baremetal=ahci1,gpt2  f24c114f-f71c-4834-8aa3-357788352a2f
		else
		  search --no-floppy --fs-uuid --set=root f24c114f-f71c-4834-8aa3-357788352a2f
		fi
		echo	'Loading Linux 6.1.9-gentoo-x86_64 ...'
		linux	/boot/vmlinuz-6.1.9-gentoo-x86_64 root=UUID=f24c114f-f71c-4834-8aa3-357788352a2f ro single
		echo	'Loading initial ramdisk ...'
		initrd	/boot/initramfs-6.1.9-gentoo-x86_64.img
	}
	menuentry 'Gentoo GNU/Linux, with Linux 5.15.80-gentoo-x86_64' --class gentoo --class gnu-linux --class gnu --class os $menuentry_id_option 'gnulinux-5.15.80-gentoo-x86_64-advanced-f24c114f-f71c-4834-8aa3-357788352a2f' {
		load_video
		if [ "x$grub_platform" = xefi ]; then
			set gfxpayload=keep
		fi
		insmod gzio
		insmod part_gpt
		insmod ext2
		set root='hd1,gpt2'
		if [ x$feature_platform_search_hint = xy ]; then
		  search --no-floppy --fs-uuid --set=root --hint-bios=hd1,gpt2 --hint-efi=hd1,gpt2 --hint-baremetal=ahci1,gpt2  f24c114f-f71c-4834-8aa3-357788352a2f
		else
		  search --no-floppy --fs-uuid --set=root f24c114f-f71c-4834-8aa3-357788352a2f
		fi
		echo	'Loading Linux 5.15.80-gentoo-x86_64 ...'
		linux	/boot/vmlinuz-5.15.80-gentoo-x86_64 root=UUID=f24c114f-f71c-4834-8aa3-357788352a2f ro
		echo	'Loading initial ramdisk ...'
		initrd	/boot/initramfs-5.15.80-gentoo-x86_64.img
	}
	menuentry 'Gentoo GNU/Linux, with Linux 5.15.80-gentoo-x86_64 (recovery mode)' --class gentoo --class gnu-linux --class gnu --class os $menuentry_id_option 'gnulinux-5.15.80-gentoo-x86_64-recovery-f24c114f-f71c-4834-8aa3-357788352a2f' {
		load_video
		if [ "x$grub_platform" = xefi ]; then
			set gfxpayload=keep
		fi
		insmod gzio
		insmod part_gpt
		insmod ext2
		set root='hd1,gpt2'
		if [ x$feature_platform_search_hint = xy ]; then
		  search --no-floppy --fs-uuid --set=root --hint-bios=hd1,gpt2 --hint-efi=hd1,gpt2 --hint-baremetal=ahci1,gpt2  f24c114f-f71c-4834-8aa3-357788352a2f
		else
		  search --no-floppy --fs-uuid --set=root f24c114f-f71c-4834-8aa3-357788352a2f
		fi
		echo	'Loading Linux 5.15.80-gentoo-x86_64 ...'
		linux	/boot/vmlinuz-5.15.80-gentoo-x86_64 root=UUID=f24c114f-f71c-4834-8aa3-357788352a2f ro single
		echo	'Loading initial ramdisk ...'
		initrd	/boot/initramfs-5.15.80-gentoo-x86_64.img
	}
	menuentry 'Gentoo GNU/Linux, with Linux 5.15.80-gentoo-x86_64.old' --class gentoo --class gnu-linux --class gnu --class os $menuentry_id_option 'gnulinux-5.15.80-gentoo-x86_64.old-advanced-f24c114f-f71c-4834-8aa3-357788352a2f' {
		load_video
		insmod gzio
		insmod part_gpt
		insmod ext2
		set root='hd1,gpt2'
		if [ x$feature_platform_search_hint = xy ]; then
		  search --no-floppy --fs-uuid --set=root --hint-bios=hd1,gpt2 --hint-efi=hd1,gpt2 --hint-baremetal=ahci1,gpt2  f24c114f-f71c-4834-8aa3-357788352a2f
		else
		  search --no-floppy --fs-uuid --set=root f24c114f-f71c-4834-8aa3-357788352a2f
		fi
		echo	'Loading Linux 5.15.80-gentoo-x86_64.old ...'
		linux	/boot/vmlinuz-5.15.80-gentoo-x86_64.old root=UUID=f24c114f-f71c-4834-8aa3-357788352a2f ro
		echo	'Loading initial ramdisk ...'
		initrd	/boot/initramfs-5.15.80-gentoo-x86_64.img.old
	}
	menuentry 'Gentoo GNU/Linux, with Linux 5.15.80-gentoo-x86_64.old (recovery mode)' --class gentoo --class gnu-linux --class gnu --class os $menuentry_id_option 'gnulinux-5.15.80-gentoo-x86_64.old-recovery-f24c114f-f71c-4834-8aa3-357788352a2f' {
		load_video
		insmod gzio
		insmod part_gpt
		insmod ext2
		set root='hd1,gpt2'
		if [ x$feature_platform_search_hint = xy ]; then
		  search --no-floppy --fs-uuid --set=root --hint-bios=hd1,gpt2 --hint-efi=hd1,gpt2 --hint-baremetal=ahci1,gpt2  f24c114f-f71c-4834-8aa3-357788352a2f
		else
		  search --no-floppy --fs-uuid --set=root f24c114f-f71c-4834-8aa3-357788352a2f
		fi
		echo	'Loading Linux 5.15.80-gentoo-x86_64.old ...'
		linux	/boot/vmlinuz-5.15.80-gentoo-x86_64.old root=UUID=f24c114f-f71c-4834-8aa3-357788352a2f ro single
		echo	'Loading initial ramdisk ...'
		initrd	/boot/initramfs-5.15.80-gentoo-x86_64.img.old
	}
}

### END /etc/grub.d/10_linux ###

### BEGIN /etc/grub.d/20_linux_xen ###

### END /etc/grub.d/20_linux_xen ###

### BEGIN /etc/grub.d/30_os-prober ###
### END /etc/grub.d/30_os-prober ###

### BEGIN /etc/grub.d/30_uefi-firmware ###
menuentry 'UEFI Firmware Settings' $menuentry_id_option 'uefi-firmware' {
	fwsetup
}
### END /etc/grub.d/30_uefi-firmware ###

### BEGIN /etc/grub.d/40_custom ###
# This file provides an easy way to add custom menu entries.  Simply type the
# menu entries you want to add after this comment.  Be careful not to change
# the 'exec tail' line above.
### END /etc/grub.d/40_custom ###

### BEGIN /etc/grub.d/41_custom ###
if [ -f  ${config_directory}/custom.cfg ]; then
  source ${config_directory}/custom.cfg
elif [ -z "${config_directory}" -a -f  $prefix/custom.cfg ]; then
  source $prefix/custom.cfg
fi
### END /etc/grub.d/41_custom ###

#nano -w /etc/fstab
#       documentation for details on setting a label. To obtain the UUID, use
#       the blkid(8) command.

#LABEL=boot		/boot		ext4		noauto,noatime	1 2
#UUID=58e72203-57d1-4497-81ad-97655bd56494		/		ext4		noatime		0 1
#LABEL=swap		none		swap		sw		0 0
#/dev/cdrom		/mnt/cdrom	auto		noauto,ro	0 0
/dev/sdb2                /              ext4
/dev/sdb3                /mnt/daten     ext4           user,rw
/dev/sdb1                /mnt/efi       vfat           user,rw
#/dev/sdc1               /mnt/beide     vfat           user, rw
/dev/sdc2                               swap
